TFLW-4000WDR-04Z1-3385
tongfei
| Quantity: | |
|---|---|
product technical parameter
| MODEL | TFLW-4000 | TFLW-6000 | TFLW-8000 | TFLW-10000 | TFLW-12000 | |
| VOLTAGE | 380V | |||||
| FREQUENCY | 3-50HZ | |||||
| CURRENT | 15.4 | 15 | 19.8 | 20.8 | 25 | |
| MAX.PUMP FLOW | 2.5L/min+30L/min | 2.5L/min+40L/min | 3L/min+60L/min | 3L/min+60L/min | 3L/min+100L/min | |
| MAX.PUMP LIFT | 30 | 30 | 30 | 30 | 35 | |
| WATER TEMPERATURE RANGE | MAJOR LOOP:15~35℃,PRECISION:±1℃ REFLECTOR PATH:20~40℃,PRECISION±2℃ | |||||
| CIRCULATE WATER | USE DEIONIZED WATER OR PURIFIED WATER | |||||
| ENVIRONMENT TEMPERATURE | 5~45℃ | |||||
| NOISE LEVEL | ≤75 | |||||
| PROTECTION CLASS | IP44 | |||||
| MAJOR LOOP INTERFACE DIMENSION(WATER OUTLET) | 1″ | 1″ | 1″ | 1″ | 1 1 / 4 ″ | |
| MAJOR LOOP INTERFACE DIMENSION(WATER INLET) | 1″ | 1″ | 1″ | 1″ | 1 1 / 4 ″ | |
| REFLECTOR PATH INTERFACE DIMENSION(WATER OUTLET) | 1/2″ | 1/2″ | 1/2″ | 1/2″ | 1/2″ | |
| REFLECTOR PATH INTERFACE DIMENSION(WATER INLET) | 1/2″ | 1/2″ | 1/2″ | 1/2″ | 1/2″ | |
| DIMENSION W*D*H | 760×842×1610 | 830×935×1850 | 830×1035×1930 | 830×1035×1930 | 960×1050×1900 | |
| TANK CAPACITY | 130L | 130L | 130L | 130L | 130L | |
| WEIGHT | 240 | 290 | 320 | 345 | 380 | |
Functions and Features
1.Adopting high-quality stainless steel cold water circulation pump, with large flow rate, high head, low noise, and long service life; Plastic water tanks, stainless steel pipelines, and valves are free from rust;
2. The control system adopts a liquid crystal controller, which displays the cooling water temperature in real-time. The CPU is fully automatic and can achieve human-machine dialogue, making the operation simple and intuitive.
3. Water temperature control accuracy ± 1 ℃; Equipped with automatic fault diagnosis function, directly displaying fault points on the screen, prompting users to quickly handle them;
4. Provide RS485 communication interface to achieve communication with the host
Provide multiple protection functions, passive alarm terminals, and remote control terminals, making it easy to achieve centralized control and monitoring of CNC;
Packing details
