Rfl-C2000h
raycus
| Quantity: | |
|---|---|
Product technical parameters
| optical characteristics | |
| Rated output power: (W): | 2000 |
| Center wavelength: (nm): | 1080 ± 5 |
| Maximum modulation frequency (kHz): | 5 |
| Output power stability: | ± 1.5% |
| Red light: | Yes |
| output characteristic | |
| Output connector method: | QBH (customizable) |
| Beam quality M ²: | 2-6 (50 μ M) |
| Polarization state: | random |
| Output fiber length (m): | 20 (customizable) |
| Electrical control characteristics | |
| Input power supply (VAC): | 220 ± 10%, single-phase |
| Control mode: | external RS232, external AD, Ethernet |
| Power regulation range (%): | 10-100 |
| Other features | |
| Size (mm) W * H * D: | 440 * 586 * 149 (including handle) |
| Weight (kg): | < 25 |
| Cooling method: | water cooling |
| Working temperature (ºC): | 10-40 |
Product features
1.High electro-optical conversion efficiency
2.Customizable output fiber length
3.QBH connector
4.Maintenance free operation
5.Wide modulation frequency range
6.Anti high reactivity
7.Efficient thin plate cutting
Product application
Precision cutting
Metal welding
Thin plate punching
Metal marking
surface treatment
3D printing and rapid prototyping
